  3. Nickel Tab with Adhesive Polymer for Pouch Cell Negative Terminal
Public – Prices Hidden
Nickel Tab with Adhesive Polymer for Pouch Cell Negative Terminal

Nickel Tab with Adhesive Polymer for Pouch Cell Negative Terminal

https://www.s4r.fr/shop/nickel-tab-with-adhesive-polymer-for-pouch-cell-negative-terminal-114 https://www.s4r.fr/web/image/product.template/114/image_1920?unique=cff4d79

High-purity nickel tabs with adhesive polymer layer for pouch cell negative terminal connection.

Available in multiple widths for laboratory and pilot-scale battery assembly.

0.00 € 0.0 EUR 0.00 €

Pricing available to approved customers

Add this product to a quote request, or sign in to view your pricing.

  • Width (mm)

This combination does not exist.

No account required. Add the products you need, then send your request to our technical sales team.

Request Pricing Access
Pouch Cell Components · Negative Terminal Tab

Nickel tab with adhesive polymer for pouch-cell negative terminal

High-purity nickel tabs with an adhesive polymer film for pouch-cell negative terminal connection. Available in four widths for laboratory and pilot-scale battery assembly.

≥99.99 %
Nickel purity
3 → 15 mm
Tab width range
0.09 → 0.35 mm
Nickel thickness
4 variants
Tab dimensions
Key features

Nickel negative-terminal tabs for pouch-cell assembly

High-purity nickel tabs with an adhesive polymer film for pouch-cell anode current-collector connection.

High-purity nickel

Nickel material with a specified purity of ≥99.99 %.

Adhesive polymer film

Negative-terminal tab supplied with an adhesive polymer film.

Four width variants

Available in 3, 4, 8 and 15 mm tab widths with matched thickness and current rating.

Pouch-cell connection

Intended for pouch-cell anode current-collector connection.

Available variants

Four nickel tab dimensions

Each width is supplied with its specified length, nickel thickness, current indication and packaging.

3 mm
60 mm length
0.10 mm Ni
3 A
40 pcs / box
4 mm
61 mm length
0.09 mm Ni
3 A
50 pcs / box
8 mm
60 mm length
0.09 mm Ni
10 A
50 pcs / box
15 mm
44 mm length
0.35 mm Ni
Higher load
50 pcs / box
Product data

Technical specifications

Material, application and dimensional data for the S4R nickel tab variants.

Width Length Thickness (Ni) Max current Packaging
3 mm 60 mm 0.10 mm 3 A 40 pcs / box
4 mm 61 mm 0.09 mm 3 A 50 pcs / box
8 mm 60 mm 0.09 mm 10 A 50 pcs / box
15 mm 44 mm 0.35 mm Higher load 50 pcs / box
Applications

Pouch-cell negative terminal connection

Nickel tabs with an adhesive polymer film for pouch-cell anode current-collector connection and battery assembly.

Negative terminal
Designed as a negative-terminal tab for pouch cells.
Anode connection
Intended for pouch-cell anode current-collector connection.
Laboratory & pilot-scale assembly
Four dimensions for laboratory and pilot-scale battery assembly.
