  3. Copper Foam Sheet Current Collector – 0.5 mm / 1.6 mm Thickness, 480 × 300 mm for Lithium-Ion Battery and Fuel Cell Research
Public – Prices Hidden
Copper Foam Sheet Current Collector – 0.5 mm / 1.6 mm Thickness, 480 × 300 mm for Lithium-Ion Battery and Fuel Cell Research

Copper Foam Sheet Current Collector – 0.5 mm / 1.6 mm Thickness, 480 × 300 mm for Lithium-Ion Battery and Fuel Cell Research

https://www.s4r.fr/web/image/product.template/106/image_1920?unique=ce393d6

This open-cell copper foam sheet is used as a high-porosity current collector substrate for lithium-ion battery and fuel cell research. Supplied in 480 × 300 mm format, it is available in 0.5 mm and 1.6 mm thickness options to accommodate different mechanical and loading requirements.

With purity ≥99.9%, porosity ranging from 50–98%, and through-hole rate ≥98%, the three-dimensional conductive structure enables efficient electrolyte penetration and active material coating in laboratory-scale electrochemical applications.

0.00 € 0.0 EUR 0.00 €

Worldwide shipping

Shipping costs and lead time confirmed with your quotation.

Secure payment

Card payment and purchase orders accepted.

Technical support

Configuration and compatibility support from our engineers.

Pricing available to approved customers

Sign in to view your pricing, or request access to an S4R professional account.

  • Thickness (mm)

This combination does not exist.

Request Pricing Access
Specification
Material Copper (Purity ≥99.9%)
Structure Open-cell copper foam sheet
Thickness Options 0.5 mm / 1.6 mm
Length 480 mm
Width 300 mm
Pore Size 0.1–1 mm (5–120 ppi)
Porosity 50–98 %
Through-Hole Rate ≥ 98 %
Volume Density 0.1–0.8 g/cm³
Form Sheet (rolled for shipping)
